Pump Suction Type
Toxic and Harmful Gas Detector
OVERVIEW
MS100 is a hand-held pump-type gas detector. It adopts ABS+PC housing, excellent performance, and various indicators, and adopts brand-new imported sensors and a low power consumption ARM processor. Independent high precision imported ADC analog-to-digital conversion chip, with the company's unique signal processing algorithm, the measurement results are more accurate and stable.
FEATURES & BENEFITS
* Imported high-performance sensor, long service life;
* Built-in high-performance air pump, the flow rate is stable, can switch control;
* Navigation button, user-friendly and easy to operate;
* Can store 100,000 sets of data;
* Intelligent algorithm, more accurate measurement results;
* 2600mA large capacity lithium battery, continuous working time of more than 20 hours (electrochemical principle);
* %VOL, %LEL, mg/m3, PPM, PPH, PPB units can be selected;
SPECIFICATION
| Number | Type of gas | Range | Respond timeT90 (S) |
| 1 | ASH3 | 0-5ppm | <90 |
| 2 | Br2 | 0-20/200ppm | <60 |
| 3 | C2H2 | 0-10/100ppm | <90 |
| 4 | C2H4 | 0-10/100ppm | <80 |
| 5 | CH2O | 0-10/50ppm | <80 |
| 6 | CH3SH | 0-10ppm | <90 |
| 7 | CH4 | 0-100%LEL | <30 |
| 8 | CL2 | 0-10/50/200ppm | <90 |
| 9 | CLO2 | 0-1/50ppm | <90 |
| 10 | CO | 0-100/500/1000ppm | <30 |
| 11 | ETO | 0-10/100/500ppm | <120 |
| 12 | H2 | 0-1000/40000ppm | <60 |
| 13 | H2O2 | 0-100/500ppm | <60 |
| 14 | H2S | 0-100/1000ppm | <60 |
| 15 | HCL | 0-50/200ppm | <80 |
| 16 | HCN | 0-50ppm | <30 |
| 17 | HF | 0-10/100ppm | <90 |
| 18 | NH3 | 0-20/100/1000ppm | <90 |
| 19 | NO | 0-250/2000ppm | <60 |
| 20 | NO2 | 0-20/2000ppm | <60 |
| 21 | O2 | 0-30%VOL | <25 |
APPLICATION
The detector is widely used in petroleum, chemical industry, environmental protection, metallurgy, refining, biochemical medicine, agriculture, explosion prevention.
The detector can effectively predict the concentration of dangerous gas alarms, to ensure that the safety of staff life is not threatened, and production equipment is not lost.
